CCTV 9CH 10CH 4K NVR H.265++ Network Video Recorder 9 Channel 5MP 8MP NVR HD Output Support Cloud App mobile monitoring Xmeye
$37,99$43,99 Select options
Sale!

CCTV 9CH 10CH 4K NVR H.265++ Network Video Recorder 9 Channel 5MP 8MP NVR HD Output Support Cloud App mobile monitoring Xmeye

$37,99$43,99

-53%
ChinaPolandRussian FederationSPAINUkraine
8CH9CH
Clear



For Wholesale and Quotations it takes 1-3 days to get your quote according to the item complexity. The shown price is for reference and may change according to the market.



Enquiries about the products can be through our official channels using email, social media and chatbot.



This link include 8CH and 9CH optional, The corresponding products are as follows:

The difference of two Boards:

1: XM chip not support wifi adapter

2: The working temperature XM board will be more hot than Hi3536 board

3: Feeling of using the boards, Hi3536 chip will More flexible

1. HDD question:
We recommend use the Newest HDD.
Use the security HDD will work more better.
PC HDD most can not work.
2.IP Camera 264 and 265 question:
This one only support the xmeye IP camera H.265,
if you use the dahua or hik camera, nvr will not match all of their cameras and not support h.265
3. VGA and HDMI question:
NVR have a defult display resolution,Your monitor must use the same resolution then will work first time. The second you can change the nvr output resolution as you need.

Face Record/Face Detection/Face Playback
Record every face that appears on the lens, without missing any details.
You need use the Face Detction Function IP Camera


Hi3536 Support 10CH 4K IP Camera


XM Newest Firmware Support 9CH 4K IP Camera


Langauages:
English,Russian,Italian,Portuguese,Spanish,French,Germany.,etc…
Total 28 languages

7601 Wifi adapter
The 10CH Hi3536 board support Wifi adapter
The 9CH XM board not support Wifi adapter
(This link is not include wifi adapter, if you need, please press the below photo to buy)


Motion Detection & Email Alert/Record
when motion is detected, the NVR can send email or start record to the hard disk without missing any important events.



Hi3536 Max Support the 4K Display
XM Board Max Support 1920x1080P Display


Advanced H.265++ Video Compression
H.265 (HEVC) doubles the coding efficiency compared with its predecessor H.264. That means H.265++ video saves around 70% of the bit rate at the same quality of coding.

Easy remote access Anytime anywhere
P2P technology supports remote access on the mobile device,Just intall the APP on your phone by scanning the QR cade or storing from the APP View the camera remotely anytime, any where. PC use the www.xmeye.net to visit the camera.



Gift SATA Data and Power cable

Interface Definition

Model
NBD8010S-KL-V2
10CH 4K
System
Main processor
Hi3536
Operating System
Embedded Linux
System resources
Simultaneous multi-channel real-time recording, playback, network operation, USB backup
Interface
Operator interface
16-bit true color graphic menu operation interface, support mouse operation
Preview
1/4/9/10
Video
Video input (IP)
10*4K(72Mbps in)
Access bandwidth
64Mbps
Forwarding bandwidth
36Mbps
Video compression
H.265AI/H.265+ (Compatible with H.265/H.264)
Display quality
Max 4K
Playback quality
4K
Decode
4K
VR
Unsupport
human shape / Face
Support(Depend on Xmeye camera)
Audio
Audio compression
G.711A
Intercom
unsupport
Record & playback
Recording mode
Manual>Alarm>Dynamic Detection>Timing
Local payback
4K
Search mode
Search by Time/Calendar/Event/Channel
Record storage
HDD,Network
Backup mode
Network backup, USB hard disk, USB burner, SATA burner
External interface
Video output
1ch VGA,1ch HD output
Audio I/O
0/1(3.5MM audio output)
Alarm I/O
0/0
Network interface
1*RJ45 10M/100M Adaptive Ethernet port
USB interface
2*USB2.0 ports
HDD
1* SATA(Up to 8TB for each disk)
ESATA
No
Serial interface
No
Other
Power supply
12V/2A
(This link is not include Power supply)
Power Consumption
<10W(Without HDD)
Work environment
Temperature:0℃ -55℃ , Humidity:10%-90%RH , Atm:86kpa-106kp
Dimension
118mm*46mm
Weight
A total of about 44g

Model

NBD80X09S-KL9CH 4K

System

Main processor

XM8536D

Operating System

Embedded Linux

System resources

Simultaneous multi-channel real-time recording, playback, network operation, USB backup

Interface

Operator interface

16-bit true color graphic menu operation interface, support mouse operation

Preview

1/2/4/6/8/9

Video

Video input (IP)

9*4K Unreal-time(Access bandwidth 60Mbps)

Video compression

H.265AI/H.265+(compatible H.265/H.264)

Display quality

Max:1920*1080

Playback quality

4K/5M/4M/3M/1080P

Decode

1ch4k/1ch5M/1ch4M/2ch3M/3ch1080P

VR

support

human shape / Face

Support(depend on camera)

Audio

Audio compression

G.711A

Intercom

support

Record&playback

Recording mode

Manual>Alarm>Dynamic Detection>Timing

Local payback

1ch4k/1ch5M/1ch4M/2ch3M/3ch1080P

Search mode

Search by Time/Calendar/Event/Channel/Face

Record storage

HDD、Network

Backup mode

Network backup, USB hard disk, USB burner, SATA burner

External interface

Video output

1ch VGA,1ch HDMI HD output

Audio I/O

1/1(3.5mm)

Alarm I/O

0/0

Network interface

1*RJ4510M/100MAdaptiveEthernetport

USB interface

2*USB2.0 ports(one USB extension interface is reserved)

HDD

1* SATA(Up to 14TB for each disk)

ESATA

No

Serial interface

No

Other

Power supply

12V/2A(Not include)

Power Consumption

<10W(Without HDD)

Work environment

Temperature:0℃ -55℃, Humidity:10%-90%RH , Atm:86kpa-106kp

Dimension

118mm*46mm

Weight

A total of about 63g

New Style Win10 Menu







Additional information

Brand Name

USAFEQLO

Origin

CN(Origin)

Smart home platform

Other

Certification

NONE

Technology

Network

Supported Operating Systems

Microsoft Windows 7

e-Cloud(P2P)

Yes

Video Output

1CH HDMI-compatible 1920X1080 60Hz

IP Mode

Static IP address

Video Standard

PAL

Hard Drive Size

3.5''

Network Protocol

PPPoE

Network Interface

RJ45 10/100M

Backup Type

Hard Drive

Audio Output

None

Video Input Interface

RJ45

Supported Mobile Systems

Android

Two-way Audio

Yes

Video Resolution

5MP

Compression Format

H.265

Wireless Security

WPA2

Audio Compression Format

G711A

Hard drive Interface Type

SATA

Communication Interface

None

Model Number

USA-NBD8008RA-GLK

Alarm Action

Local Alarm

POE

None

Audio Input

1 Channel

Main processor

XM/ Hi3536

Video compression

H.265/H.264

Display quality

XM is 1080P/ Hi3536 is 4K

Playback quality

XM is 4K / Hi3536 is 4K

HDD

1* SATA(Up to 8TB for each disk)

9CH

XM is 9CH 4K/ Hi3536 is 10CH 4K

Face Identification

Support

WIFI

XM not support/ Hi3536 support
